Netforce- D486

Network Switch

Product Overview

The D-486 is a L3 managed switch featuring 48 Gigabit RJ45 ports and 6 × 10G SFP+ slots, designed to deliver high throughput and advanced management features. Ideal for growing businesses, it serves as both an edge switch for demanding workgroups and a backbone for high-speed servers or gigabit switches.

  • 6 × 10Gbps SFP+ uplink ports
  • Supports VLAN, QoS, ACL, SSL, and SNMP
  • Web, CLI, Telnet, SSH, SNMPv1/v2/v3 management
  • 48 × 10/100/1000Mbps RJ45 ports
  • 802.1X, ARP/IP/DoS protection, Port security, MAC/IP binding
  • Spanning Tree (STP/RSTP/MSTP) and ERPS ring protection
Certified Quality Standards
Rigorous Testing
& Validation
Comprehensive Support
Reliable Performance

Industry we serve

Delivering reliable network solutions with enhanced security

Service Providers

Scale with cutting-edge optics and meet increasing bandwidth demands

Enterprise

Enable secured, real-time data and get an edge over your competitors

Data Centers

Future-proof interconnects between center, state and local institutions

Government

Build trusted, pro-active networks for servers, switches, and storages


Features

  • 48 × 10/100/1000 Mbps RJ45 ports and 6 × 10 Gbps SFP+ uplink ports for high-speed network expansion.
  • Layer 3 static routing support for both IPv4 and IPv6 networks.
  • 216 Gbps switching capacity with a forwarding rate of 160.704 Mpps for high-throughput performance.
  • 32K MAC address table and jumbo frame support up to 10K bytes for large-scale enterprise environments.
  • VLAN segmentation support including Port-based VLAN, Voice VLAN, and Surveillance VLAN.
  • Multiple QoS priority modes including Port-based, 802.1p, DSCP, and IP TOS for traffic prioritization.
  • Queue scheduling algorithms support SP, WRR, WFQ, and hybrid scheduling.
  • Supports IGMP Snooping v1/v2/v3 and MLD Snooping for optimized multicast and video streaming.
  • Multicast VLAN Registration (MVR) support for efficient IP surveillance and broadcasting.
  • Static and Dynamic Link Aggregation (LACP) for increased bandwidth and link redundancy.
  • Supports STP, RSTP, MSTP, and ERPS for loop prevention and enhanced network resilience.
  • 802.1X authentication with dynamic VLAN assignment for secure user access control.

Standard Compliance

  • Complies with IEEE 802.3i / 802.3u / 802.3ab standards for reliable Ethernet networking.
  • Supports IEEE 802.1Q VLAN tagging for efficient network segmentation.
  • Implements STP, RSTP, and MSTP protocols for loop prevention and network redundancy.
  • Quality of Service (QoS) based on 802.1p and DSCP standards for traffic prioritization.
  • Secure management and access supported via SSL, TLS, SSH, and HTTPS encryption protocols.

Characteristics

  • 216 Gbps switching capacity with a forwarding rate of 160.704 Mpps for high-throughput data processing.
  • 32K MAC address table and jumbo frame support up to 10K bytes for large-scale enterprise network handling.
  • Store-and-Forward switching mechanism ensures reliable and accurate packet processing.
  • Comprehensive security features including 802.1X authentication, ARP protection, IP/MAC/Port binding, and DoS attack prevention.
  • Designed for stable operation within a 0°C to 45°C temperature range with low-humidity tolerance.
