Lotus Alpha- AX820

Fast. Stable. Intelligent

Product Overview

The Immunity Networks Lotus Alpha is a next-generation Wi-Fi 6 (802.11ax) indoor access point, designed for high-density environments, offering high throughput and robust reliability. With a combined wireless speed of 1800 Mbps across dual radios (2.4 GHz + 5 GHz), it supports MU-MIMO, OFDMA, advanced modulation, and seamless roaming. It is ideal for campus settings, offices, warehouses, or any environment requiring strong, stable indoor wireless coverage.

  • 1,800 Mbps combined speed across 2.4 GHz (600 Mbps, 2×2) and 5 GHz (1,200 Mbps, 2×2)
  • 360° omnidirectional signal, BSS color, dynamic CCA/SD threshold adaptation, and long OFDM symbol support.
  • Supports 120+ concurrent users, ideal for high-density use cases.
  • Supports 1024-QAM, MU-MIMO (uplink + downlink), OFDMA, and TWT (Target Wake Time) for efficient, multi-user performance.
  • Works via PoE or external adapter for flexible deployment.
  • Full IP rating (IP61), ceiling-mountable design, and enterprise-level software feature set.
Certified Quality Standards
Rigorous Testing
& Validation
Comprehensive Support
Reliability is Key

Industry we serve

Fast Data Transfer Across All Connected Devices

Education

Reliable Wi-Fi for classrooms, libraries, and hostels.

Enterprise

Stable, high-speed connectivity for employees and visitors.

Retail

Smooth connectivity for stores, malls, and point-of-sale systems.

Public Institutions

Network access for government offices and community centers.


Features

  • Wireless data rate up to 1.8Gbps. 802.11ax supports 1024QAM.
  • Long OFDM symbol.
  • 160M bandwidth and 11ax 2x2 MIMO technology.
  • The wireless data rate up to 1.8Gbps.
  • Meet with demand for high-speed applications such as VR/ AR, 4K or 8K stream media.
  • Advanced 1024-QAM Modulation Mode. 802.11ax adopt 1024-QAM modulation
  • Combined 1800 Mbps wireless speed across 2.4 GHz (600 Mbps, 11ax 2×2) and 5 GHz (1200 Mbps, 2×2) radios.
  • Equipped with Gigabit WAN and LAN ports for faster Ethernet data transmission.
  • Supports MU-MIMO and DL/UL-OFDMA modulation for efficient multi-user communication.
  • Allows multiple users to upload and download data simultaneously without congestion.
  • Features narrower subcarrier spacing and longer symbol time for improved stability and data processing.

Compliance

  • Complies with IEEE 802.11a/b/g/n/ac/ax wireless standards.
  • Supports Wi-Fi 6 (802.11ax) for high-efficiency wireless communication.
  • Meets IEEE 802.3af/at PoE power standards.
  • Adheres to IP67 rating for dustproof and waterproof protection.
  • Follows FCC, CE, and RoHS regulatory and environmental compliance standards.
  • Compatible with WPA3/WPA2-PSK, WPA/WPA2-Enterprise security protocols.
  • Supports 802.11i for enhanced wireless security encryption.
  • Conforms to 802.11k/v/r for seamless roaming performance.

Characteristics

TWT Operation
  • 802.11ax supports TWT (Target Wake-up Time).
  • Allowing devices to negotiate when needed to wake up, send and receive data.
  • Wireless AP can group the device into different TWT cycles.
Wi-Fi Coverage
  • 802.11ax supports a long OFDM symbol transmission mechanism.
  • 2MHz narrowband transmission.
  • Effectively reduced the packet loss rate and noise interference.
Anti-Interference Control Ability
  • 802.11ax supports BSS color bit and dynamic CCA-SD (Clear Channel Assessment Signal Detection) threshold and power adjustment.
  • Effectively alleviates the channel interference in multi-users scenarios.
  • Improve the utilization of spectrum resources.
