Netforce- E822

Managed Switch

Product Overview

The E822 is a high-performance Layer 2+ Managed Gigabit PoE Switch designed to meet the networking demands of modern enterprises, campuses, and service providers. It is Equipped with 8 Gigabit RJ45 PoE+ ports, 2 Gigabit SFP uplink ports, and 1 Console port, this switch delivers superior data throughput and intelligent management.

  • 8 × Gigabit PoE+ ports, 2 × SFP uplinks, and 1 × console port for seamless network expansion.
  • 20 Gbps switching capacity with a fanless, energy-efficient design for quiet reliability.
  • Delivers 130W total PoE power, compliant with IEEE 802.3af/at, ideal for IP cameras and access points.
  • Advanced L2+ features including VLAN, QoS, ACL, and SNMP for intelligent traffic control.
  • Enterprise-grade protection against unauthorized access and network attacks.
  • ERPS ring recovery <20 ms and 4 kV lightning protection for maximum uptime and safety.
Certified Quality Standards
Rigorous Testing
& Validation
Comprehensive Support
Reliable Performance

Industry we serve

Delivering reliable network solutions with enhanced security

Service Providers

Scale with cutting-edge optics and meet increasing bandwidth demands

Enterprise

Enable secured, real-time data and get an edge over your competitors

Data Centers

Future-proof interconnects between center, state and local institutions

Government

Build trusted, pro-active networks for servers, switches, and storages


Features

  • 8 × 10/100/1000 Mbps RJ45 PoE+ ports (up to 30 W per port, 130 W total PoE power budget).
  • 2 × Gigabit SFP fiber uplinks + 1 Console port for flexible connectivity.
  • 20 Gbps switching capacity with 14.88 Mpps forwarding rate.
  • Store-and-Forward switching architecture ensuring reliable packet delivery.
  • AI Smart PoE with watchdog auto-recovery for unresponsive PD devices.
  • ERPS ring protection (<20 ms recovery) for carrier-grade uptime.
  • Fanless, silent operation with energy-efficient design.
  • 4 kV lightning protection on service ports for surge resilience.
  • Internal power supply (100–240 V AC) for stable power delivery.
  • Full metal 19-inch rackmount chassis for robust installation.
  • VCT and DDM (Digital Diagnostic Monitoring) for real-time diagnostics.
  • Intuitive Web-based GUI (HTTPS) for easy configuration and control.
  • SNMP v1/v2/v3 and Syslog for centralized monitoring.
  • Supports CLI, Telnet, and SSH for secure administrative access.

Standard Compliance

  • IEEE 802.3i – 10BASE-T Ethernet.
  • IEEE 802.3u – 100BASE-TX Fast Ethernet.
  • IEEE 802.3ab – 1000BASE-T Gigabit Ethernet.
  • IEEE 802.3z – 1000BASE-X Gigabit Fiber.
  • IEEE 802.3x – Full Duplex Flow Control.
  • IEEE 802.3az – Energy Efficient Ethernet.
  • IEEE 802.3af / 802.3at – Power over Ethernet (PoE/PoE+).
  • IEEE 802.1Q – VLAN Tagging.
  • IEEE 802.1p – QoS Priority Tagging.
  • IEEE 802.1D / 802.1w / 802.1s – STP/RSTP/MSTP.
  • IEEE 802.1X – Port-Based Network Access Control.

Characteristics

TWT Operation
  • Switching Capacity: 20 Gbps.
  • Forwarding Rate: 14.88 Mpps.
  • PoE Power Budget: 130 W (Max 30 W per port).
  • MAC Address Table: 8K entries.
  • Packet Buffer: 4 Mb.
  • Lightning Protection: 4 kV.
  • Redundancy: ERPS (<20 ms recovery).
  • Management: Web (HTTPS), CLI, SNMP, Telnet, SSH.
  • Power Input: 100–240 V AC, internal PSU.
  • Cooling System: Fanless (silent operation).
  • Mounting: 19-inch rackmount, full metal chassis.
  • Operating Temperature: -10°C to +55°C.
