Gateway Controller-IGC(M)

Power. Protection. Performance

Product Overview

The IGC-M is a high-performance rack security appliance engineered for enterprise-grade and datacenter environments. Designed for 1U rack-mount integration, it delivers up to 40 Gbps throughput, < 1 ms latency, and 99.999% uptime reliability. Compact yet powerful, it combines advanced security protocols, intelligent traffic management, and energy-efficient performance (under 120 W power consumption) by offering a cost-effective and scalable solution to meet today’s most demanding network requirements

  • 21.1Gbps throughput and 5 mega packets per second.
  • Fast Filtering up to 50.000 Connections per Second
  • Operates at 1310 nm wavelength using DFB laser technology.
  • ~3.5Gbps with inline intrusion prevention.
  • Guard Web Access Filtering (SSL) Proxy. Captive Portal with Voucher suppor
  • 128GB SSD Offering Sufficient Space for Logging & Reporting
Certified Quality Standards
Rigorous Testing
& Validation
Comprehensive Support
Security is Priority

Industry we serve

We keep industries connected and performing.

Businesses

Protect networks with firewall, intrusion prevention, and traffic shaping to boost performance.

Schools

Manage bandwidth and filter unwanted content easily with built-in web filtering, no extra plugins needed.

Hotels

Provide guest internet access with a captive portal and voucher system via a simple interface.

On the Road

Secure mobile access with OpenVPN/IPSec VPN, two-factor authentication, and easy client setup.

Branches & SOHO

Create secure site-to-site VPNs with IPsec or SSL, simple setup, and support for ZeroTier, Tinc, and Wireguard.


Features

  • Up to 21.1 Gbps firewall throughput and 3.5 Gbps intrusion prevention
  • 16-core high-performance processor for enterprise-grade workloads
  • 2.5 Gbps IPsec VPN throughput (AES-256-GCM16) for secure connectivity
  • Integrated Intrusion Prevention System (IPS) and Web Filtering Proxy
  • Captive Portal with voucher-based access management
  • Dual Power Supply with automatic failover and 93% power efficiency
  • MTBF over 2.4 million hours (200+ years reliability)
  • 2× SFP+ (10 Gbps) and 6× RJ45 (2.5 Gbps) ports for flexible networking
  • 128 GB SSD for logging and expandable DDR4 memory
  • Noise level below 42 dB(A) with low power consumption
  • Centralized GUI dashboard for real-time monitoring and analytics
  • Scalable up to 4093 VLANs and multi-WAN connectivity

Compliance

  • AES-256-GCM16 (FIPS 140-2 Compliant)
  • Two-Factor (TOTP / Google Authenticator)
  • IPv4 / IPv6 Dual Stack
  • IEEE 802.1Q (Up to 4093 VLANs)
  • IEEE 802.3ad LACP & Cisco EtherChannel
  • CE, FCC, RoHS Compliant
  • IEC 60950 / 62368-1

Characteristics

Ports
  • 2 × SFP+/SFP28 (10/25 Gbps)
  • 6 × RJ45 (2.5 Gbps)
  • 1 × USB 3.0, 1 × Console Port
Performance
  • 21.1 Gbps Firewall Throughput
  • 3.5 Gbps Threat Protection
  • 2.5 Gbps IPsec VPN Throughput
  • 50,000 New Connections/sec
  • 63 Million Concurrent Sessions
  • 100 μs Average Latency
Operating Conditions
  • Temperature: 0°C to +45°C
  • Humidity: 10–90% non-condensing
  • Power Input: 100–240 VAC, 50–60 Hz
  • Power Consumption: 85–250 W
  • Heat Dissipation: 273 BTU/hr
